Omaa Metal Sources is ANSI/ASME B16.5 ASTM B564 Inconel 601 Flanges Exporters and Suppliers in the US, UK, South Africa, Saudi Arabia, Singapore, UAE, Oman, South Korea, Turkey, Bahrain, Malaysia, Philippines, Thailand, Norway, Indonesia, Iraq, Yemen, Bangladesh, Nigeria, Egypt, Peru, Ghana, Morocco, Etc.
ASTM B564 Inconel Alloy 601 Flanges Manufacturer, UNS N06601 Weld Neck Flange, Inconel 601 Slip-on Flange, WNR 2.4851 Lap Joint Flange, Alloy 601 Blind Flange
Inconel 601 is a nickel-chromium alloy that is known for its high-temperature strength and oxidation resistance. Inconel 601 flanges are typically used in applications where high-temperature and/or corrosive environments are present, such as in the chemical processing, petrochemical, and power generation industries.
Some of the key properties of Inconel 601 flanges include:
- High-temperature strength: Inconel 601 has excellent strength at high temperatures, making it ideal for use in applications where high-temperature resistance is required.
- Oxidation resistance: Inconel 601 is highly resistant to oxidation, which is the process by which materials break down when exposed to oxygen at high temperatures. This makes it suitable for use in environments where oxidation is a concern.
- Corrosion resistance: Inconel 601 is also highly resistant to corrosion, particularly in environments where sulfur compounds are present.
- Weldability: Inconel 601 can be welded using a variety of techniques, including gas tungsten arc welding (GTAW) and gas metal arc welding (GMAW).
Inconel 601 flanges are available in a variety of sizes and pressure ratings to suit different applications. They can be purchased from a range of manufacturers and suppliers, and are typically made to industry standards such as ANSI, ASME, and ASTM. When selecting Inconel 601 flanges, it is important to ensure that they are suitable for the intended application and that they meet the necessary quality and performance standards.
ASME SB564 Inconel Alloy 601 RTJ Flange, PN10 PN16 ASME / ANSI B16.5 Alloy 601 Threaded Flange, Table D & Table E Inconel 601 Spectacle Blind Flange, ANSI 150 Inconel Grade 601 Socket Weld Flange at the Lowest Prices
Inconel 601 Flange Specifications
Size Range
1/2" (15 NB) to 48" (1200NB) DN10~DN5000
Class / Pressure Rating
150#, 300#, 600#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64 etc.
Standards / Dimensions
ANSI/ASME B16.5, B16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, BS, GOST, MSS SP-44, ISO70051, JISB2220, BS1560-3.1, API7S-15, API7S-43, API605
Connection Type
Ring Joint Flange (RTJ), Flat Face Flange (FF), Raised Face Flange (RF), Male and Female Flange (M & F), Lap Joint Flange, Large and Small Tongue-and-Groove Flange (T & G)
Material Standards
ASTM B564/ ASME SB564
ASTM B564 Inconel 601 Flanges Equivalent Grade
STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
---|---|---|---|---|---|---|---|
Inconel 601 | 2.4851 | N06601 | NCF 601 | NA 49 | XH60BT | NC23FeA | NiCr23Fe |
ANSI B16.5 Inconel 601 Flanges Chemical Composition
Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
---|---|---|---|---|---|---|---|---|
Inconel 601 | 0.10 max | 1.00 max | 0.50 max | 0.015 max | 1.00 max | Balance | 58.0 – 63.0 | 21.0 – 25.0 |
ASTM B564 Inconel Alloy 601 Flanges Mechanical Properties
Grade | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
---|---|---|---|---|---|
Inconel 601 | 8.1 g/cm3 | 1411 °C (2571 °F) | Psi – 80,000 , MPa – 550 | Psi – 30,000 , MPa – 205 | 30 % |
Find the largest ready stock of DIN 2.4851 Socket Weld Flanges, Nickel Alloy NiCr23Fe Reducing Flanges, Inconel UNS N06601 High Hub Blinds Flanges, Alloy 601 Orifice Flange, Inconel 601 Flange, Inconel 601 Plate Flange, Alloy 601 PN40 Blind Flange, ASME SB564 Inconel 601 Slip On Flanges Dealer, Inconel 601 Forged Flanges, ASTM B564 Inconel 601 weldo Flanges, 601 Inconel BLRF Flanges, Inconel UNS N06601 Flanges, Inconel 601 Ring Type Joint Flange, NCF 601 Blind Flanges, ASME SB564 Inconel Alloy 601 Spectacle Blind Flanges, Class 300#, 600#, 900#, 1500#, 2500# Inconel 601 Flanges in Mumbai, India.
B564 Inconel Alloy 601 Flanges Dimensions & Size
NPS (in.) | Inconel 601 Flanges Dimensions | ||||
---|---|---|---|---|---|
Dia. of Flange (in.) | No. of Bolts | Dia. of Bolts (in.) | Dia. of Bolt Holes (in.) | Bolt Circle (in.) | |
1/4 | 3-3/8 | 4 | 1/2 | 0.62 | 2-1/4 |
1/2 | 3-1/2 | 4 | 1/2 | 0.62 | 2-3/8 |
3/4 | 3-7/8 | 4 | 1/2 | 0.62 | 2-3/4 |
1 | 4-1/4 | 4 | 1/2 | 0.62 | 3-1/8 |
1-1/4 | 4-5/8 | 4 | 1/2 | 0.62 | 3-1/2 |
1-1/2 | 5 | 4 | 1/2 | 0.62 | 3-7/8 |
2 | 6 | 4 | 5/8 | 0.75 | 4-3/4 |
2-1/2 | 7 | 4 | 5/8 | 0.75 | 5-1/2 |
3 | 7-1/2 | 4 | 5/8 | 0.75 | 6 |
3-1/2 | 8-1/2 | 8 | 5/8 | 0.75 | 7 |
4 | 9 | 8 | 5/8 | 0.75 | 7-1/2 |
5 | 10 | 8 | 3/4 | 0.88 | 8-1/2 |
6 | 11 | 8 | 3/4 | 0.88 | 9-1/2 |
8 | 13-1/2 | 8 | 3/4 | 0.88 | 11-3/4 |
10 | 16 | 12 | 7/8 | 1 | 14-1/4 |
12 | 19 | 12 | 7/8 | 1 | 17 |
14 | 21 | 12 | 1 | 1.12 | 18-3/4 |
16 | 23-1/2 | 16 | 1 | 1.12 | 21-1/4 |
18 | 25 | 16 | 1-1/8 | 1.25 | 22-3/4 |
20 | 27-1/2 | 20 | 1-1/8 | 1.25 | 25 |
24 | 32 | 20 | 1-1/4 | 1.38 | 29-1/2 |
API and ASME/ANSI Inconel 601 Flanges Dimensions
ASME ANSI vs. API flanges with the same dimensions | ||||
Flange | Pressure Class Rating (psi) (kPa) | Nominal Size Range (inches) | ||
---|---|---|---|---|
ASME/ANSI B16.5 | API 6A | ASME/ANSI B16.5 | API 6A1) | |
Weld neck | 600 | 2000 | 1/2 – 24 | 113/16 – 11 |
900 | 3000 | |||
1500 | 5000 | |||
Blind and Threaded | 600 | 2000 | 113/16 – 211/4 | |
900 | 3000 | 113/16 – 203/4 | ||
1500 | 5000 | 113/16 – 11 | ||
In the old API standard, flanges ranged from 1 1/2 to 10(20) inches. 1 inch = 25.4 mm |
ATM B564 Inconel Alloy 601 Flanges Weight Chart
Standard | Class | Bolt Hole Dia | Dia of Bolt Circle | Dia | Size of Bolt | Bolts Number |
---|---|---|---|---|---|---|
Flange AS 2129 | ||||||
Table D Flanges | 14 | 67 | 95 | 13 | 4 | |
Table C Flanges | 14 | 67 | 95 | 13 | 4 | |
Table J Flanges | 17 | 83 | 114 | 16 | 4 | |
Table F Flanges | 14 | 67 | 95 | 13 | 4 | |
Table E Flanges | 14 | 67 | 95 | 13 | 4 | |
Table H Flanges | 17 | 83 | 114 | 16 | 4 | |
Flanges AS4087 | ||||||
Flanges ANSI B16.5 | ANSI 150 Flanges | 16 | 60 | 89 | 13 | 4 |
PN14 Flanges | 14 | 67 | 95 | M12 | 4 | |
ANSI 1500 Flanges | 22 | 83 | 121 | 19 | 4 | |
ANSI 600 Flanges | 16 | 67 | 95 | 13 | 4 | |
ANSI 300 Flanges | 16 | 67 | 95 | 13 | 4 | |
ANSI 900 Flanges | 22 | 83 | 121 | 19 | 4 | |
Flange ISO 7005 (DIN) | PN10 Flanges | 14 | 65 | 95 | M12 | 4 |
PN6 Flanges | 11 | 55 | 80 | M10 | 4 | |
PN40 Flanges | 14 | 65 | 95 | M12 | 4 | |
PN20 Flanges | 16 | 60.5 | 90 | M14 | 4 | |
PN16 Flanges | 14 | 65 | 95 | M12 | 4 | |
PN25 Flanges | 14 | 65 | 95 | M12 | 4 |
Alloy Grade 601 Flange Pressure Ratings
Inconel Alloy 601 Flanges Pressure And Temperature Ratings | |||||||
Temperature °F | Class 150 As Per ASME B16.5 | Class 300 As Per ASME B16.5 | Class 400 As Per ASME B16.5 | Class 600 As Per ASME B16.5 | Class 900 As Per ASME B16.5 | Class 1500 As Per ASME B16.5 | Class 2500 As Per ASME B16.5 |
-20 to 100 | 275 | 720 | 960 | 1440 | 2160 | 3600 | 6000 |
200 | 230 | 600 | 800 | 1200 | 1800 | 3000 | 5000 |
300 | 205 | 540 | 720 | 1080 | 1620 | 2700 | 4500 |
400 | 190 | 495 | 660 | 995 | 1490 | 2485 | 4140 |
500 | 170 | 465 | 620 | 930 | 1395 | 2330 | 3880 |
600 | 140 | 435 | 580 | 875 | 1310 | 2185 | 3640 |
650 | 125 | 430 | 575 | 860 | 1290 | 2150 | 3580 |
700 | 110 | 425 | 565 | 850 | 1275 | 2125 | 3540 |
750 | 95 | 415 | 555 | 830 | 1245 | 2075 | 3460 |
800 | 80 | 405 | 540 | 805 | 1210 | 2015 | 3360 |
850 | 65 | 395 | 530 | 790 | 1190 | 1980 | 3300 |
900 | 50 | 390 | 520 | 780 | 1165 | 1945 | 3240 |
950 | 35 | 380 | 510 | 765 | 1145 | 1910 | 3180 |
1000 | 20 | 320 | 430 | 640 | 965 | 1605 | 2675 |
1050 | 20 | 310 | 410 | 615 | 925 | 1545 | 2570 |
1100 | 20 | 255 | 345 | 515 | 770 | 1285 | 2145 |
1150 | 20 | 200 | 265 | 400 | 595 | 995 | 1655 |
1200 | 20 | 155 | 205 | 310 | 465 | 770 | 1285 |
1250 | 20 | 115 | 150 | 225 | 340 | 565 | 945 |
1300 | 20 | 85 | 115 | 170 | 255 | 430 | 715 |
1350 | 20 | 60 | 80 | 125 | 185 | 310 | 515 |
1400 | 20 | 50 | 65 | 95 | 145 | 240 | 400 |
1450 | 15 | 35 | 45 | 70 | 105 | 170 | 285 |
1500 | 10 | 25 | 35 | 55 | 80 | 135 | 230 |
ANSI B16.5 Inconel 601 Flanges Schedule / Class
Flange Schedule/Class | Pipe Size – Pipe Flanges | Flange Connection Type | Flange Material | Max. Pressure |
---|---|---|---|---|
ASME B16.5 Class 150 | 1/2″ | FNPT | Inconel 601 / Alloy Grade 601 / ASTM B564 601 Flange | 150 psi |
ASME B16.5 Class 150 | 1/2″ | Socket Weld | 275 psi | |
ASME B16.5 Class 150 | 1/2″ | Welded | 150 psi | |
ASME B16.5 Class 150 | 3/4″ | FNPT | 150 psi | |
ASME B16.5 Class 150 | 3/4″ | Socket Weld | 275 psi | |
ASME B16.5 Class 150 | 1-1/4″ | Socket Weld | 275 psi | |
ASME B16.5 Class 150 | 1-1/2″ | Socket Weld | 275 psi | |
ASME B16.5 Class 150 | 2″ | FNPT | 150 psi | |
ASME B16.5 Class 150 | 2″ | Socket Weld | 275 psi | |
ASME B16.5 Class 150 | 2-1/2″ | Socket Weld | 275 psi | |
ASME B16.5 Class 150 | 3″ | Socket Weld | 275 psi | |
ASME B16.5 Class 150 | 4″ | FNPT | 150 psi | |
ASME B16.5 Class 150 | 4″ | Socket Weld | 275 psi | |
ASME B16.5 Class 300 | 1/2″ | Slip On | 720 psi | |
ASME B16.5 Class 300 | 1/2″ | Slip On | 720 psi | |
ASME B16.5 Class 300 | 1″ | Slip On | 720 psi | |
ASME B16.5 Class 300 | 1″ | Slip On | 720 psi | |
ASME B16.5 Class 300 | 1-1/4″ | FNPT | 720 psi | |
ASME B16.5 Class 300 | 1-1/4″ | Slip On | 720 psi | |
ASME B16.5 Class 300 | 1-1/2″ | Slip On | 720 psi | |
ASME B16.5 Class 300 | 1-1/2″ | Slip On | 720 psi | |
ASME B16.5 Class 300 | 2″ | Slip On | 720 psi | |
ASME B16.5 Class 300 | 2″ | Slip On | 720 psi | |
ASME B16.5 Class 300 | 2-1/2″ | Slip On | 720 psi | |
ASME B16.5 Class 300 | 2-1/2″ | Slip On | 720 psi | |
ASME B16.5 Class 300 | 3″ | Slip On | 720 psi | |
ASME B16.5 Class 300 | 3″ | Slip On | 720 psi | |
ASME B16.5 Class 300 | 4″ | Slip On | 720 psi | |
ASME B16.5 Class 300 | 4″ | Slip On | 720 psi |
Inconel Grade 601 Flanges Dimensional Size Chart
Normal Sizes In inch | Dimension | Inconel 601 Flanges Dimensional Sizes 1/2 inch. to 2 1/2 inch. | ||||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Class 125 Class 150 | Class 300 | Class 400 | Class 600 | Class 900 | Class 1500 | Class 2500 | ||||||||||
inch. | mm | inch. | millimeter | inch. | mm | inch. | mm | inch. | mm | inch. | mm | inch | mm | |||
1/2 | A | 3 1/2 | 88.9 | 3 3/4 | 95.2 | 3 3/4 | 95.2 | 3 3/4 | 95.2 | 4 3/4 | 121 | 4 3/4 | 121 | 5 1/4 | 133.4 | |
b | 7/16 | 11.1 | 9/16 | 14.3 | 9/16 | 14.3 | 9/16 | 14.3 | 7/8 | 22.2 | 7/8 | 22.2 | 1 3/16 | 30.2 | ||
D2 | 1 3/8 | 34.9 | 1 3/8 | 34.9 | 1 3/8 | 34.9 | 1 3/8 | 34.9 | 1 3/8 | 34.9 | 1 3/8 | 34.9 | 1 3/8 | 34.9 | ||
D1 | 2 3/8 | 60.3 | 2 5/8 | 66.7 | 2 5/8 | 66.7 | 2 5/8 | 66.7 | 3 1/4 | 82.6 | 3 1/4 | 82.6 | 3 1/2 | 88.9 | ||
n | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | – | 4 | 44 | ||
d | 5/8 | 15.9 | 5/8 | 15.9 | 5/8 | 15.9 | 5/8 | 15.9 | 7/8 | 22.2 | 7/8 | 22.2 | 7/8 | 22.2 | ||
3/4 | A | 3 7/8 | 98.4 | 4 5/8 | 117.5 | 4 5/8 | 117.5 | 4 5/8 | 117.5 | 5 1/8 | 130 | 5 1/8 | 130 | 5 1/2 | 139.7 | |
b | 1/2 | 12.7 | 5/8 | 15.9 | 5/8 | 15.9 | 5/8 | 15.9 | 1 | 25.4 | 1 | 25.4 | 1 1/4 | 31.8 | ||
D2 | 1 11/16 | 42.9 | 1 11/16 | 42.9 | 1 11/16 | 42.9 | 1 11/16 | 42.9 | 1 11/16 | 42.9 | 1 11/16 | 42.9 | 1 11/16 | 42.9 | ||
D1 | 2 3/4 | 69.8 | 3 1/4 | 82.5 | 3 1/4 | 82.5 | 3 1/4 | 82.5 | 3 1/2 | 88.9 | 3 1/2 | 88.9 | 3 3/4 | 95.2 | ||
n | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | – | 4 | 44 | ||
d | 5/8 | 15.9 | 3/4 | 19 | 3/4 | 19 | 3/4 | 19 | 7/8 | 22.2 | 7/8 | 22.2 | 7/8 | 22.2 | ||
1 | A | 4 1/4 | 108 | 4 7/8 | 123.8 | 4 7/8 | 123.8 | 4 7/8 | 123.8 | 5 7/8 | 149.2 | 5 7/8 | 149.2 | 6 1/4 | 159 | |
b | 9/16 | 14.3 | 11/16 | 17.5 | 11/16 | 17.5 | 11/16 | 17.5 | 1 1/8 | 28.6 | 1 1/8 | 28.6 | 1 3/8 | 34.9 | ||
D2 | 2 | 50.8 | 2 | 50.8 | 2 | 50.8 | 2 | 50.8 | 2 | 50.8 | 2 | 50.8 | 2 | 50.8 | ||
D1 | 3 1/8 | 79.4 | 3 1/2 | 88.9 | 3 1/2 | 88.9 | 3 1/2 | 88.9 | 4 | 102 | 4 | 102 | 4 1/4 | 108 | ||
n | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | ||
d | 5/8 | 15.9 | 3/4 | 19 | 3/4 | 19 | 3/4 | 19 | 1 | 25.4 | 1 | 25.4 | 1 | 25.4 | ||
1 1/4 | A | 4 5/8 | 117.5 | 5 1/4 | 133.4 | 5 1/4 | 133.4 | 5 1/4 | 133.4 | 6 1/4 | 159 | 6 1/4 | 159 | 7 1/4 | 184.2 | |
b | 5/8 | 15.9 | 3/4 | 19 | 13/16 | 20.6 | 13/16 | 20.6 | 1 1/8 | 28.6 | 1 1/8 | 28.6 | 1 1/2 | 38.1 | ||
D2 | 2 1/2 | 63.5 | 2 1/2 | 63.5 | 2 1/2 | 63.5 | 2 1/2 | 63.5 | 2 1/2 | 63.5 | 2 1/2 | 63.5 | 2 1/2 | 63.5 | ||
D1 | 3 1/2 | 88.9 | 3 7/8 | 98.4 | 3 7/8 | 98.4 | 3 7/8 | 98.4 | 4 3/8 | 111 | 4 3/8 | 111 | 5 1/8 | 130 | ||
n | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | ||
d | 5/8 | 15.9 | 3/4 | 19 | 3/4 | 19 | 3/4 | 19 | 1 | 25.4 | 1 | 25.4 | 1 1/8 | 28.6 | ||
1 1/2 | A | 5 | 127 | 6 1/8 | 155.6 | 6 1/8 | 155.6 | 6 1/8 | 155.6 | 7 | 177.8 | 7 | 177.8 | 8 | 203 | |
b | 11/16 | 17.5 | 13/16 | 20.6 | 7/8 | 22.2 | 7/8 | 22.2 | 1 1/4 | 31.8 | 1 1/4 | 31.8 | 1 3/4 | 44.5 | ||
D2 | 2 7/8 | 73 98 | 2 7/8 | 73 | 2 7/8 | 73 | 2 7/8 | 73 | 2 7/8 | 73 | 2 7/8 | 73 | 2 7/8 | 73 | ||
D1 | 3 7/8 | 4 | 4 1/2 | 114 | 4 1/2 | 114 | 4 1/2 | 114 | 4 7/8 | 124 | 4 7/8 | 124 | 5 3/4 | 146 | ||
n | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | ||
d | 5/8 | . 15.9 | 7/8 | 22.2 | 7/8 | 22.2 | 7/8 | 22.2 | 1 1/8 | 28.6 | 1 1/8 | 28.6 | 1 1/4 | 31.8 | ||
2 | A | 6 | 152.4 | 6 1/2 | 165.1 | 6 1/2 | 165.1 | 6 1/2 | 165.1 | 8 1/2 | 215.9 | 8 1/2 | 215.9 | 9 1/4 | 234.9 | |
b | 3/4 | 19 | 7/8 | 22.2 | 1 | 25.4 | 1 | 25.4 | 1 1/2 | 38.1 | 1 1/2 | 38.1 | 2 | 50.8 | ||
D2 | 3 5/8 | 92.1 | 3 5/8 | 92.1 | 3 5/8 | 92.1 | 3 5/8 | 92.1 | 3 5/8 | 92.1 | 3 5/8 | 92.1 | 3 5/8 | 92.1 | ||
D1 | 4 3/4 | 121 | 5 | 127 | 5 | 127 | 5 | 127 | 6 1/2 | 165.1 | 6 1/2 | 165.1 | 6 3/4 | 171 | ||
n | 4 | 4 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | ||
d | 3/4 | 19 | 3/4 | 19 | 3/4 | 19 | 3/4 | 19 | 1 | 25.4 | 1 | 25.4 | 1 1/8 | 28.6 | ||
2 1/2 | A | 7 | 177.8 | 7 1/2 | 190.5 | 7 1/2 | 190.5 | 7 1/2 | 190.5 | 9 5/8 | 244 | 9 5/8 | 244 | 10 1/2 | 266.7 | |
b | 7/8 | 22.2 | 1 | 25.4 | 1 1/8 | 28.6 | 1 1/8 | 28.6 | 1 5/8 | 41.3 | 1 5/8 | 41.3 | 2 1/4 | 57.2 | ||
D2 | 4 1/8 | 104.8 | 4 1/8 | 104.8 | 4 1/8 | 104.8 | 4 1/8 | 104.8 | 4 1/8 | 105 | 4 1/8 | 105 | 4 1/8 | 105 | ||
D1 | 5 1/2 | 139.7 | 5 7/8 | 149.2 | 5 7/8 | 149.2 | 5 7/8 | 149.2 | 7 1/2 | 190.5 | 7 1/2 | 190.5 | 7 3/4 | 197 | ||
n | 4 | 4 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | ||
d | 3/4 | 19 | 7/8 | 22.2 | 7/8 | 22.2 | 7/8 | 22.2 | 1 1/8 | 28.6 | 1 1/8 | 28.6 | 1 1/4 | 31.8 |
Inconel 601 Flanges Dimensional Tolerance
Ring type, Slip-on and Blind flanges | HUB type slip-on | ||||
O.D. | <=24″ | +/- 0.6″(1.6mm) | O.D. | <=24″ | +/- 0.6″(1.6mm) |
>24″ | +/- .12″(3.2mm) | >24″ | +/- .12″(3.2mm) | ||
I.D. | Socket-Welding | 10″ and Samller +.03″(0.8mm),-0″ | I.D. | 10″ and Samller | +.03″(0.8mm) |
Slip-on and Lap Joint | 12″ and Larger +.06″(1.6mm),-0″ | 12″-18″ | +/-.06″(1.6mm) | ||
20″-42″ | +.12″(3.2mm) +.06″(1.6mm) | ||||
O.D. of Hub | <=12″ | +.09″(2.4mm), -.06″(1.6mm) | Diameter of Contact Face | 0.06″ Raised Face | +/-.03″(0.8mm) |
14″-42″ | +/-.12″(3.2mm) | ||||
Diameter of Contact face | 0.06″ Raised Face | +/- .03″(0.8mm) | Diameter of Hub at base | X<=24″ | +/-.06″(1.6mm) |
X>24″ | +/-.12″(3.2mm) | ||||
Deameter of Contact face | <=10″ | +.03″(0.8mm), -0″ | Diameter of Hub at point of Welding | <=5″ | +.09″(2.4mm), -.03″(0.8mm) |
12″-42″ | +.06″(1.6mm), -0″ | >=6″ | +.16″(4.0mm), -.03″(0.8mm) | ||
Drilling | Bolt Circle | 1/2″-24″ /26″-42″ | Drilling | Bolt Circle | 1/2″-24″ /26″-42″ |
+/-.06″(1.6mm) +/-.06″ | +/-.06″(1.6mm) +/-.06″ | ||||
Bolt hole spacing | +/-.03″(0.8mm) | Bolt hole spacing | +/-.03″(0.8mm) | ||
Eccentricity of Bolt circle with respect to bore | .03″ Max. (0.8mm) | Eccentricity of Bolt circle with respect to bore | .03″ Max. (0.8mm) | ||
Thickness | 18″& Small | +.12″(3.2mm),-0″ | Thickness | 18″& Small | +.12″(3.2mm),-0″ |
20″-42″ | +.19″(1.6mm) | 20″-42″ | +.19″(1.6mm) | ||
Length Thru Hub | <=10″ | +/-.06″(1.6mm) | Length Thru Hub | <=10″ | +/-.06″(1.6mm) |
12″-42″ | +/1.12″(3.2mm) | 12″-42″ | +/1.12″(3.2mm) |
Best quality Inconel 601 Flanges, EN NiCr23Fe Plate Flange Flat Face, View Specification Of ASME B16.5 601 Inconel Orifice Flange, GOST XH60BT Nipoflange, Alloy 601 Threaded Flanges, Inconel 601 Flanges Supplier, Inconel 601 Forged Flanges, UNS N06601 Class 150 Flanges Raised Face, WERKSTOFF NR. 2.4851 Expander Flanges, AFNOR NC23FeA Square Flange, Inconel UNS N06601 High Hub Blinds Flanges, 601 Inconel Backup Flange, 601 Inconel Weldoflange, MSS SP-44 Inconel 601 Plate Flange, JIS NCF 601 RTJ Flange, BS NA 49 Spectacle Blind Flange at Best Price.
Inconel ASTM B564 Grade 601 Flanges Applications
- Petrochemical Industries
- Pharmaceutical Equipment
- Power Generation
- Heating Systems and Heat Exchanger
- Pulp and Paper Industry
- Mining Support
- Chemical Equipment
- Gas Processing
- Plumbing
- Nuclear Power Systems
- Condensers
- Sea Water Equipment
- Buildings and Bridges
- Industrial Water Lines
- Food Processing Industry
- Fire Protection Systems
- Off-Shore Oil Drilling Companies
Australia, Afghanistan, Algeria, Angola, Argentina, Armenia, Azerbaijan, Bahrain, Bangladesh, Benin,
Bhutan, Botswana, Brazil, Brunei, Burkina Faso, Cambodia, Cameroon, Canada, Central Africa Republic,
Chad, Chile, Colombia, Cuba, Cyprus, DRC, Djibouti, Egypt, Equatorial Guinea, Eritrea, Eswatini,
Ethiopia, Fiji, Finland, France, Georgia, Germany, Ghana, Greece, Hungary, Iceland, Indonesia, Iran,
Iraq, Ireland, Israel, Italy, Japan, Jordan, Kazakhstan, Kenya, Kuwait, Kyrgyzstan, Laos, Lebanon,
Lesotho, Liberia, Libya, Lithuania, Madagascar, Malawi, Malaysia, Maldives, Mali, Mexico, Morocco,
Mozambique, Mauritania, Myanmar, Namibia, Nepal, Netherlands, New Zealand, Nigeria, Norway, Oman,
Panama, Peru, Philippines, Poland, Portugal, Palestine, Qatar, Russia, Rwanda, Romania, Saudi Arabia,
Senegal, Sierra Leone, Singapore, Slovakia, Somalia, South Africa, South Korea, South Sudan, Spain,
Sri Lanka, Sweden, Switzerland, Syria, Taiwan, Tajikistan, Tanzania, Tasmania, Thailand, The Gambia,
Timor-Leste, Togo, Tunisia, Turkey, Turkiye, Turkmenistan, Uganda, Uzbekistan, United Arab Emirates (UAE),
United Kingdom (UK), United States (US), Venezuela, Vietnam, Yemen, Zambia, Zimbabwe
Abu Dhabi, Amsterdam, Abuja, Accra, Addis Ababa, Ahmedabad, Algiers, Amman, Ankara, Antananarivo,
Ashgabat, Asmara, Astana, Athens, Baghdad, Baku, Bamako, Bandar Seri Begawan, Bangkok, Bangui,
Banjul, Beirut, Bengaluru, Berlin, Bishkek, Bloemfontein, Bogotá, Bern, Brasília, Bratislava,
Bucharest, Budapest, Buenos Aires, Cairo, Canberra, Cape Town, Caracas, Chennai, Coimbatore, Dakar,
Damascus, Dhaka, Dili, Djibouti city, Dodoma, Doha, Dublin, Dushanbe, Freetown, Gaborone, Ghaziabad,
Guwahati, Hanoi, Harare, Havana, Helsinki, Hobart, Hyderabad, Indore, Jaipur, Jakarta, Jerusalem,
Juba, Jurong East, Kabul, Kampala, Kanpur, Kathmandu, Kigali, Kinshasa, Kochi, Kolkata, Kuala Lumpur,
Kuwait City, Lisbon, Lilongwe, Lima, Lobamba, Lomé, London, Luanda, Lucknow, Lusaka, Malabo, Madrid,
Malé, Mexico City, Manama, Moscow, Manila, Maputo, Maseru, Mbabane, Mogadishu, Monrovia, Mumabi,
Muscat, Nagpur, Nairobi, New Delhi, Niamey, Nicosia, Noida, Nouakchott, N’Djamena, Oslo, Ottawa,
Ouagadougou, Panama City, Paris, Patna, Phnom Penh, Porto-Novo, Pretoria, Pune, Rabat, Reykjavík,
Riyadh, Rome, Sana’a, Santiago, Sri Jayawardenepura Kotte, Stockholm, Seoul, Singapore, Surat,
Suva, Taipei City, Tashkent, Tokyo, Tbilisi, Tehran, Thimphu, Tripoli, Tunis, Vientiane, Vilnius,
Visakhapatnam, Warsaw, Washington D.C., Wellington, Windhoek, Yaoundé, Yerevan, Naypyidaw
