ASTM B564 Incoloy Alloy 330 Flanges Manufacturer, UNS N08330 Weld Neck Flange, Incoloy 330 Slip-on Flange, WNR 1.4886 Lap Joint Flange, RA 330 Blind Flange
Incoloy 330, also known as SS 330 or Ra 330, is a high-temperature alloy that is often used in applications where resistance to thermal expansion and oxidation is required. Flanges made from Incoloy 330/SS 330/Ra 330 are commonly used in high-temperature industrial processes, such as heat treating, furnace components, and power generation.
These flanges are typically manufactured to ASTM specifications, such as ASTM B564, which covers nickel alloy forgings. Incoloy 330/SS 330/Ra 330 flanges can be provided in various sizes and pressure ratings, and they can be produced in several different configurations, such as weld neck, slip-on, threaded, and socket weld.
When selecting Incoloy 330/SS 330/Ra 330 flanges, it is important to consider factors such as the specific application requirements, the operating conditions, and the type of piping system that will be used. It is also important to ensure that the flanges are manufactured to the appropriate standards and that they are installed and maintained correctly to ensure optimal performance and safety.
ASME SB564 Incoloy Alloy 330 RTJ Flange, PN10 PN16 ASME / ANSI B16.5 Alloy 330 Threaded Flange, Table D & Table E Incoloy 330 Spectacle Blind Flange, ANSI 150 Incoloy SS 330 Socket Weld Flange at the Lowest Prices
Incoloy 330 Flange Specifications
Size Range
1/2" (15 NB) to 48" (1200NB) DN10~DN5000
Class / Pressure Rating
150#, 300#, 600#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64 etc.
Standards / Dimensions
ANSI/ASME B16.5, B16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, BS, GOST, MSS SP-44, ISO70051, JISB2220, BS1560-3.1, API7S-15, API7S-43, API605
Connection Type
Ring Joint Flange (RTJ), Flat Face Flange (FF), Raised Face Flange (RF), Male and Female Flange (M & F), Lap Joint Flange, Large and Small Tongue-and-Groove Flange (T & G)
Material Standards
ASTM B564/ ASME SB564
ASTM B564 Incoloy 330 Flanges Equivalent Grade
STANDARD | WERKSTOFF NR. | UNS |
---|---|---|
Incoloy 330 | 1.4886 | N08330 |
ANSI B16.5 Incoloy 330 Flanges Chemical Composition
Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr | Sn | Pb |
---|---|---|---|---|---|---|---|---|---|---|
330 | 0.08 max | 2.00 max | 0.75-1.50 | 0.03 max | 1.00 max | Balance | 34.0-37.0 | 17.0-20.0 | 0.025 | 0.005 max |
ASTM B564 Incoloy 330 Flanges Mechanical Properties
Properties | Metric | Imperial |
---|---|---|
Tensile strength(annealed) | 600 MPa | 87 ksi |
Yield strength(annealed) | 280 MPa | 40.6 ksi |
Elongation at Break | 45% | 45% |
Find the largest ready stock of ASTM B564 Incoloy 330 Flanges, ASTM B564 Ra 330 Exhaust Flanges, WERKSTOFF NR. 21.4886 SORF Flanges, UNS N08330 Orifice Flanges, ANSI B16.5 SS 330 Long Weld Neck Flanges, Incoloy Alloy 330 Blind Flanges, ASTM B564 330 Incoloy Exhaust Flanges, Incoloy 330 Hub Blind Flanges, DIN 1.4886 Reducing Flanges, ASME B16.11 Ra 330 Puddle Flanges, ASTM B564 SS 330 Alloy Nipolet Flanges, ANSI B16.5 Incoloy 330 Plate Flanges, UNS N08330 Lap Joint Flanges, Class 300#, 600#, 900#, 1500#, 2500# Incoloy 330 Flanges in Mumbai, India.
ASTM B564 Incoloy 330 Flanges Dimensions & Size
NPS (in.) | Incoloy 330 / SS 330 / Ra 330 Flanges Dimensions | ||||
---|---|---|---|---|---|
Dia. of Flange (in.) | No. of Bolts | Dia. of Bolts (in.) | Dia. of Bolt Holes (in.) | Bolt Circle (in.) | |
1/4 | 3-3/8 | 4 | 1/2 | 0.62 | 2-1/4 |
1/2 | 3-1/2 | 4 | 1/2 | 0.62 | 2-3/8 |
3/4 | 3-7/8 | 4 | 1/2 | 0.62 | 2-3/4 |
1 | 4-1/4 | 4 | 1/2 | 0.62 | 3-1/8 |
1-1/4 | 4-5/8 | 4 | 1/2 | 0.62 | 3-1/2 |
1-1/2 | 5 | 4 | 1/2 | 0.62 | 3-7/8 |
2 | 6 | 4 | 5/8 | 0.75 | 4-3/4 |
2-1/2 | 7 | 4 | 5/8 | 0.75 | 5-1/2 |
3 | 7-1/2 | 4 | 5/8 | 0.75 | 6 |
3-1/2 | 8-1/2 | 8 | 5/8 | 0.75 | 7 |
4 | 9 | 8 | 5/8 | 0.75 | 7-1/2 |
5 | 10 | 8 | 3/4 | 0.88 | 8-1/2 |
6 | 11 | 8 | 3/4 | 0.88 | 9-1/2 |
8 | 13-1/2 | 8 | 3/4 | 0.88 | 11-3/4 |
10 | 16 | 12 | 7/8 | 1 | 14-1/4 |
12 | 19 | 12 | 7/8 | 1 | 17 |
14 | 21 | 12 | 1 | 1.12 | 18-3/4 |
16 | 23-1/2 | 16 | 1 | 1.12 | 21-1/4 |
18 | 25 | 16 | 1-1/8 | 1.25 | 22-3/4 |
20 | 27-1/2 | 20 | 1-1/8 | 1.25 | 25 |
24 | 32 | 20 | 1-1/4 | 1.38 | 29-1/2 |
API and ASME/ANSI Incoloy 330 Flanges Dimensions
ASME ANSI vs. API flanges with the same dimensions | ||||
Flange | Pressure Class Rating (psi) (kPa) | Nominal Size Range (inches) | ||
---|---|---|---|---|
ASME/ANSI B16.5 | API 6A | ASME/ANSI B16.5 | API 6A1) | |
Weld neck | 600 | 2000 | 1/2 – 24 | 113/16 – 11 |
900 | 3000 | |||
1500 | 5000 | |||
Blind and Threaded | 600 | 2000 | 113/16 – 211/4 | |
900 | 3000 | 113/16 – 203/4 | ||
1500 | 5000 | 113/16 – 11 | ||
In the old API standard, flanges ranged from 1 1/2 to 10(20) inches. 1 inch = 25.4 mm |
ASTM B564 Incoloy 330 Flanges Weight Chart
Standard | Class | Bolt Hole Dia | Dia of Bolt Circle | Dia | Size of Bolt | Bolts Number |
---|---|---|---|---|---|---|
Flange AS 2129 | ||||||
Table D Flanges | 14 | 67 | 95 | 13 | 4 | |
Table C Flanges | 14 | 67 | 95 | 13 | 4 | |
Table J Flanges | 17 | 83 | 114 | 16 | 4 | |
Table F Flanges | 14 | 67 | 95 | 13 | 4 | |
Table E Flanges | 14 | 67 | 95 | 13 | 4 | |
Table H Flanges | 17 | 83 | 114 | 16 | 4 | |
Flanges AS4087 | ||||||
Flanges ANSI B16.5 | ANSI 150 Flanges | 16 | 60 | 89 | 13 | 4 |
PN14 Flanges | 14 | 67 | 95 | M12 | 4 | |
ANSI 1500 Flanges | 22 | 83 | 121 | 19 | 4 | |
ANSI 600 Flanges | 16 | 67 | 95 | 13 | 4 | |
ANSI 300 Flanges | 16 | 67 | 95 | 13 | 4 | |
ANSI 900 Flanges | 22 | 83 | 121 | 19 | 4 | |
Flange ISO 7005 (DIN) | PN10 Flanges | 14 | 65 | 95 | M12 | 4 |
PN6 Flanges | 11 | 55 | 80 | M10 | 4 | |
PN40 Flanges | 14 | 65 | 95 | M12 | 4 | |
PN20 Flanges | 16 | 60.5 | 90 | M14 | 4 | |
PN16 Flanges | 14 | 65 | 95 | M12 | 4 | |
PN25 Flanges | 14 | 65 | 95 | M12 | 4 |
Incoloy Alloy Grade 330 Flange Pressure Ratings
Incoloy 330 Flanges Pressure And Temperature Ratings | |||||||
Temperature °F | Class 150 As Per ASME B16.5 | Class 300 As Per ASME B16.5 | Class 400 As Per ASME B16.5 | Class 600 As Per ASME B16.5 | Class 900 As Per ASME B16.5 | Class 1500 As Per ASME B16.5 | Class 2500 As Per ASME B16.5 |
-20 to 100 | 275 | 720 | 960 | 1440 | 2160 | 3600 | 6000 |
200 | 230 | 600 | 800 | 1200 | 1800 | 3000 | 5000 |
300 | 205 | 540 | 720 | 1080 | 1620 | 2700 | 4500 |
400 | 190 | 495 | 660 | 995 | 1490 | 2485 | 4140 |
500 | 170 | 465 | 620 | 930 | 1395 | 2330 | 3880 |
600 | 140 | 435 | 580 | 875 | 1310 | 2185 | 3640 |
650 | 125 | 430 | 575 | 860 | 1290 | 2150 | 3580 |
700 | 110 | 425 | 565 | 850 | 1275 | 2125 | 3540 |
750 | 95 | 415 | 555 | 830 | 1245 | 2075 | 3460 |
800 | 80 | 405 | 540 | 805 | 1210 | 2015 | 3360 |
850 | 65 | 395 | 530 | 790 | 1190 | 1980 | 3300 |
900 | 50 | 390 | 520 | 780 | 1165 | 1945 | 3240 |
950 | 35 | 380 | 510 | 765 | 1145 | 1910 | 3180 |
1000 | 20 | 320 | 430 | 640 | 965 | 1605 | 2675 |
1050 | 20 | 310 | 410 | 615 | 925 | 1545 | 2570 |
1100 | 20 | 255 | 345 | 515 | 770 | 1285 | 2145 |
1150 | 20 | 200 | 265 | 400 | 595 | 995 | 1655 |
1200 | 20 | 155 | 205 | 310 | 465 | 770 | 1285 |
1250 | 20 | 115 | 150 | 225 | 340 | 565 | 945 |
1300 | 20 | 85 | 115 | 170 | 255 | 430 | 715 |
1350 | 20 | 60 | 80 | 125 | 185 | 310 | 515 |
1400 | 20 | 50 | 65 | 95 | 145 | 240 | 400 |
1450 | 15 | 35 | 45 | 70 | 105 | 170 | 285 |
1500 | 10 | 25 | 35 | 55 | 80 | 135 | 230 |
ANSI B16.5 Incoloy 330 Flanges Schedule / Class
Flange Schedule/Class | Pipe Size – Pipe Flanges | Flange Connection Type | Flange Material | Max. Pressure |
---|---|---|---|---|
ASME B16.5 Class 150 | 1/2″ | FNPT | Incoloy 330 / RA 330 / ASTM B564 SS 330 Flange | 150 psi |
ASME B16.5 Class 150 | 1/2″ | Socket Weld | 275 psi | |
ASME B16.5 Class 150 | 1/2″ | Welded | 150 psi | |
ASME B16.5 Class 150 | 3/4″ | FNPT | 150 psi | |
ASME B16.5 Class 150 | 3/4″ | Socket Weld | 275 psi | |
ASME B16.5 Class 150 | 1-1/4″ | Socket Weld | 275 psi | |
ASME B16.5 Class 150 | 1-1/2″ | Socket Weld | 275 psi | |
ASME B16.5 Class 150 | 2″ | FNPT | 150 psi | |
ASME B16.5 Class 150 | 2″ | Socket Weld | 275 psi | |
ASME B16.5 Class 150 | 2-1/2″ | Socket Weld | 275 psi | |
ASME B16.5 Class 150 | 3″ | Socket Weld | 275 psi | |
ASME B16.5 Class 150 | 4″ | FNPT | 150 psi | |
ASME B16.5 Class 150 | 4″ | Socket Weld | 275 psi | |
ASME B16.5 Class 300 | 1/2″ | Slip On | 720 psi | |
ASME B16.5 Class 300 | 1/2″ | Slip On | 720 psi | |
ASME B16.5 Class 300 | 1″ | Slip On | 720 psi | |
ASME B16.5 Class 300 | 1″ | Slip On | 720 psi | |
ASME B16.5 Class 300 | 1-1/4″ | FNPT | 720 psi | |
ASME B16.5 Class 300 | 1-1/4″ | Slip On | 720 psi | |
ASME B16.5 Class 300 | 1-1/2″ | Slip On | 720 psi | |
ASME B16.5 Class 300 | 1-1/2″ | Slip On | 720 psi | |
ASME B16.5 Class 300 | 2″ | Slip On | 720 psi | |
ASME B16.5 Class 300 | 2″ | Slip On | 720 psi | |
ASME B16.5 Class 300 | 2-1/2″ | Slip On | 720 psi | |
ASME B16.5 Class 300 | 2-1/2″ | Slip On | 720 psi | |
ASME B16.5 Class 300 | 3″ | Slip On | 720 psi | |
ASME B16.5 Class 300 | 3″ | Slip On | 720 psi | |
ASME B16.5 Class 300 | 4″ | Slip On | 720 psi | |
ASME B16.5 Class 300 | 4″ | Slip On | 720 psi |
Incoloy 330 Flanges Dimensional Size Chart
Normal Sizes In inch | Dimension | ASME SB564 Incoloy 330 Flanges Dimensional Sizes 1/2 inch. to 2 1/2 inch. | ||||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Class 125 Class 150 | Class 300 | Class 400 | Class 600 | Class 900 | Class 1500 | Class 2500 | ||||||||||
inch. | mm | inch. | millimeter | inch. | mm | inch. | mm | inch. | mm | inch. | mm | inch | mm | |||
1/2 | A | 3 1/2 | 88.9 | 3 3/4 | 95.2 | 3 3/4 | 95.2 | 3 3/4 | 95.2 | 4 3/4 | 121 | 4 3/4 | 121 | 5 1/4 | 133.4 | |
b | 7/16 | 11.1 | 9/16 | 14.3 | 9/16 | 14.3 | 9/16 | 14.3 | 7/8 | 22.2 | 7/8 | 22.2 | 1 3/16 | 30.2 | ||
D2 | 1 3/8 | 34.9 | 1 3/8 | 34.9 | 1 3/8 | 34.9 | 1 3/8 | 34.9 | 1 3/8 | 34.9 | 1 3/8 | 34.9 | 1 3/8 | 34.9 | ||
D1 | 2 3/8 | 60.3 | 2 5/8 | 66.7 | 2 5/8 | 66.7 | 2 5/8 | 66.7 | 3 1/4 | 82.6 | 3 1/4 | 82.6 | 3 1/2 | 88.9 | ||
n | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | – | 4 | 44 | ||
d | 5/8 | 15.9 | 5/8 | 15.9 | 5/8 | 15.9 | 5/8 | 15.9 | 7/8 | 22.2 | 7/8 | 22.2 | 7/8 | 22.2 | ||
3/4 | A | 3 7/8 | 98.4 | 4 5/8 | 117.5 | 4 5/8 | 117.5 | 4 5/8 | 117.5 | 5 1/8 | 130 | 5 1/8 | 130 | 5 1/2 | 139.7 | |
b | 1/2 | 12.7 | 5/8 | 15.9 | 5/8 | 15.9 | 5/8 | 15.9 | 1 | 25.4 | 1 | 25.4 | 1 1/4 | 31.8 | ||
D2 | 1 11/16 | 42.9 | 1 11/16 | 42.9 | 1 11/16 | 42.9 | 1 11/16 | 42.9 | 1 11/16 | 42.9 | 1 11/16 | 42.9 | 1 11/16 | 42.9 | ||
D1 | 2 3/4 | 69.8 | 3 1/4 | 82.5 | 3 1/4 | 82.5 | 3 1/4 | 82.5 | 3 1/2 | 88.9 | 3 1/2 | 88.9 | 3 3/4 | 95.2 | ||
n | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | – | 4 | 44 | ||
d | 5/8 | 15.9 | 3/4 | 19 | 3/4 | 19 | 3/4 | 19 | 7/8 | 22.2 | 7/8 | 22.2 | 7/8 | 22.2 | ||
1 | A | 4 1/4 | 108 | 4 7/8 | 123.8 | 4 7/8 | 123.8 | 4 7/8 | 123.8 | 5 7/8 | 149.2 | 5 7/8 | 149.2 | 6 1/4 | 159 | |
b | 9/16 | 14.3 | 11/16 | 17.5 | 11/16 | 17.5 | 11/16 | 17.5 | 1 1/8 | 28.6 | 1 1/8 | 28.6 | 1 3/8 | 34.9 | ||
D2 | 2 | 50.8 | 2 | 50.8 | 2 | 50.8 | 2 | 50.8 | 2 | 50.8 | 2 | 50.8 | 2 | 50.8 | ||
D1 | 3 1/8 | 79.4 | 3 1/2 | 88.9 | 3 1/2 | 88.9 | 3 1/2 | 88.9 | 4 | 102 | 4 | 102 | 4 1/4 | 108 | ||
n | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | ||
d | 5/8 | 15.9 | 3/4 | 19 | 3/4 | 19 | 3/4 | 19 | 1 | 25.4 | 1 | 25.4 | 1 | 25.4 | ||
1 1/4 | A | 4 5/8 | 117.5 | 5 1/4 | 133.4 | 5 1/4 | 133.4 | 5 1/4 | 133.4 | 6 1/4 | 159 | 6 1/4 | 159 | 7 1/4 | 184.2 | |
b | 5/8 | 15.9 | 3/4 | 19 | 13/16 | 20.6 | 13/16 | 20.6 | 1 1/8 | 28.6 | 1 1/8 | 28.6 | 1 1/2 | 38.1 | ||
D2 | 2 1/2 | 63.5 | 2 1/2 | 63.5 | 2 1/2 | 63.5 | 2 1/2 | 63.5 | 2 1/2 | 63.5 | 2 1/2 | 63.5 | 2 1/2 | 63.5 | ||
D1 | 3 1/2 | 88.9 | 3 7/8 | 98.4 | 3 7/8 | 98.4 | 3 7/8 | 98.4 | 4 3/8 | 111 | 4 3/8 | 111 | 5 1/8 | 130 | ||
n | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | ||
d | 5/8 | 15.9 | 3/4 | 19 | 3/4 | 19 | 3/4 | 19 | 1 | 25.4 | 1 | 25.4 | 1 1/8 | 28.6 | ||
1 1/2 | A | 5 | 127 | 6 1/8 | 155.6 | 6 1/8 | 155.6 | 6 1/8 | 155.6 | 7 | 177.8 | 7 | 177.8 | 8 | 203 | |
b | 11/16 | 17.5 | 13/16 | 20.6 | 7/8 | 22.2 | 7/8 | 22.2 | 1 1/4 | 31.8 | 1 1/4 | 31.8 | 1 3/4 | 44.5 | ||
D2 | 2 7/8 | 73 98 | 2 7/8 | 73 | 2 7/8 | 73 | 2 7/8 | 73 | 2 7/8 | 73 | 2 7/8 | 73 | 2 7/8 | 73 | ||
D1 | 3 7/8 | 4 | 4 1/2 | 114 | 4 1/2 | 114 | 4 1/2 | 114 | 4 7/8 | 124 | 4 7/8 | 124 | 5 3/4 | 146 | ||
n | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | ||
d | 5/8 | . 15.9 | 7/8 | 22.2 | 7/8 | 22.2 | 7/8 | 22.2 | 1 1/8 | 28.6 | 1 1/8 | 28.6 | 1 1/4 | 31.8 | ||
2 | A | 6 | 152.4 | 6 1/2 | 165.1 | 6 1/2 | 165.1 | 6 1/2 | 165.1 | 8 1/2 | 215.9 | 8 1/2 | 215.9 | 9 1/4 | 234.9 | |
b | 3/4 | 19 | 7/8 | 22.2 | 1 | 25.4 | 1 | 25.4 | 1 1/2 | 38.1 | 1 1/2 | 38.1 | 2 | 50.8 | ||
D2 | 3 5/8 | 92.1 | 3 5/8 | 92.1 | 3 5/8 | 92.1 | 3 5/8 | 92.1 | 3 5/8 | 92.1 | 3 5/8 | 92.1 | 3 5/8 | 92.1 | ||
D1 | 4 3/4 | 121 | 5 | 127 | 5 | 127 | 5 | 127 | 6 1/2 | 165.1 | 6 1/2 | 165.1 | 6 3/4 | 171 | ||
n | 4 | 4 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | ||
d | 3/4 | 19 | 3/4 | 19 | 3/4 | 19 | 3/4 | 19 | 1 | 25.4 | 1 | 25.4 | 1 1/8 | 28.6 | ||
2 1/2 | A | 7 | 177.8 | 7 1/2 | 190.5 | 7 1/2 | 190.5 | 7 1/2 | 190.5 | 9 5/8 | 244 | 9 5/8 | 244 | 10 1/2 | 266.7 | |
b | 7/8 | 22.2 | 1 | 25.4 | 1 1/8 | 28.6 | 1 1/8 | 28.6 | 1 5/8 | 41.3 | 1 5/8 | 41.3 | 2 1/4 | 57.2 | ||
D2 | 4 1/8 | 104.8 | 4 1/8 | 104.8 | 4 1/8 | 104.8 | 4 1/8 | 104.8 | 4 1/8 | 105 | 4 1/8 | 105 | 4 1/8 | 105 | ||
D1 | 5 1/2 | 139.7 | 5 7/8 | 149.2 | 5 7/8 | 149.2 | 5 7/8 | 149.2 | 7 1/2 | 190.5 | 7 1/2 | 190.5 | 7 3/4 | 197 | ||
n | 4 | 4 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | ||
d | 3/4 | 19 | 7/8 | 22.2 | 7/8 | 22.2 | 7/8 | 22.2 | 1 1/8 | 28.6 | 1 1/8 | 28.6 | 1 1/4 | 31.8 |
Incoloy 330 Flanges Dimensional Tolerance
Ring type, Slip-on and Blind flanges | HUB type slip-on | ||||
O.D. | <=24″ | +/- 0.6″(1.6mm) | O.D. | <=24″ | +/- 0.6″(1.6mm) |
>24″ | +/- .12″(3.2mm) | >24″ | +/- .12″(3.2mm) | ||
I.D. | Socket-Welding | 10″ and Samller +.03″(0.8mm),-0″ | I.D. | 10″ and Samller | +.03″(0.8mm) |
Slip-on and Lap Joint | 12″ and Larger +.06″(1.6mm),-0″ | 12″-18″ | +/-.06″(1.6mm) | ||
20″-42″ | +.12″(3.2mm) +.06″(1.6mm) | ||||
O.D. of Hub | <=12″ | +.09″(2.4mm), -.06″(1.6mm) | Diameter of Contact Face | 0.06″ Raised Face | +/-.03″(0.8mm) |
14″-42″ | +/-.12″(3.2mm) | ||||
Diameter of Contact face | 0.06″ Raised Face | +/- .03″(0.8mm) | Diameter of Hub at base | X<=24″ | +/-.06″(1.6mm) |
X>24″ | +/-.12″(3.2mm) | ||||
Deameter of Contact face | <=10″ | +.03″(0.8mm), -0″ | Diameter of Hub at point of Welding | <=5″ | +.09″(2.4mm), -.03″(0.8mm) |
12″-42″ | +.06″(1.6mm), -0″ | >=6″ | +.16″(4.0mm), -.03″(0.8mm) | ||
Drilling | Bolt Circle | 1/2″-24″ /26″-42″ | Drilling | Bolt Circle | 1/2″-24″ /26″-42″ |
+/-.06″(1.6mm) +/-.06″ | +/-.06″(1.6mm) +/-.06″ | ||||
Bolt hole spacing | +/-.03″(0.8mm) | Bolt hole spacing | +/-.03″(0.8mm) | ||
Eccentricity of Bolt circle with respect to bore | .03″ Max. (0.8mm) | Eccentricity of Bolt circle with respect to bore | .03″ Max. (0.8mm) | ||
Thickness | 18″& Small | +.12″(3.2mm),-0″ | Thickness | 18″& Small | +.12″(3.2mm),-0″ |
20″-42″ | +.19″(1.6mm) | 20″-42″ | +.19″(1.6mm) | ||
Length Thru Hub | <=10″ | +/-.06″(1.6mm) | Length Thru Hub | <=10″ | +/-.06″(1.6mm) |
12″-42″ | +/1.12″(3.2mm) | 12″-42″ | +/1.12″(3.2mm) |
Best quality Incoloy 330 SORF Flanges, WERKSTOFF NR. 1.4886 Spectacle Blind Flanges, Astm B564 Ra 330 Weldo Flanges, Incoloy 330 Threaded Flanges, ASTM B564 Incoloy 330 Socket Weld Flanges, ASTM B564 330 Incoloy Exhaust Flanges, ASME SB564 330 Slip-on Flanges, Alloy 330 Welding Neck Flanges, Incoloy 330 Ring Type Joint Flanges, ASTM B564 330 Expander Flanges, Incoloy 330 Puddle Flanges at Best Price.
ASME SB564 Incoloy 330 Flanges Applications
- Petrochemical Industries
- Pharmaceutical Equipment
- Power Generation
- Heating Systems and Heat Exchanger
- Pulp and Paper Industry
- Mining Support
- Chemical Equipment
- Gas Processing
- Plumbing
- Nuclear Power Systems
- Condensers
- Sea Water Equipment
- Buildings and Bridges
- Industrial Water Lines
- Food Processing Industry
- Fire Protection Systems
- Off-Shore Oil Drilling Companies
Australia, Afghanistan, Algeria, Angola, Argentina, Armenia, Azerbaijan, Bahrain, Bangladesh, Benin,
Bhutan, Botswana, Brazil, Brunei, Burkina Faso, Cambodia, Cameroon, Canada, Central Africa Republic,
Chad, Chile, Colombia, Cuba, Cyprus, DRC, Djibouti, Egypt, Equatorial Guinea, Eritrea, Eswatini,
Ethiopia, Fiji, Finland, France, Georgia, Germany, Ghana, Greece, Hungary, Iceland, Indonesia, Iran,
Iraq, Ireland, Israel, Italy, Japan, Jordan, Kazakhstan, Kenya, Kuwait, Kyrgyzstan, Laos, Lebanon,
Lesotho, Liberia, Libya, Lithuania, Madagascar, Malawi, Malaysia, Maldives, Mali, Mexico, Morocco,
Mozambique, Mauritania, Myanmar, Namibia, Nepal, Netherlands, New Zealand, Nigeria, Norway, Oman,
Panama, Peru, Philippines, Poland, Portugal, Palestine, Qatar, Russia, Rwanda, Romania, Saudi Arabia,
Senegal, Sierra Leone, Singapore, Slovakia, Somalia, South Africa, South Korea, South Sudan, Spain,
Sri Lanka, Sweden, Switzerland, Syria, Taiwan, Tajikistan, Tanzania, Tasmania, Thailand, The Gambia,
Timor-Leste, Togo, Tunisia, Turkey, Turkiye, Turkmenistan, Uganda, Uzbekistan, United Arab Emirates (UAE),
United Kingdom (UK), United States (US), Venezuela, Vietnam, Yemen, Zambia, Zimbabwe
Abu Dhabi, Amsterdam, Abuja, Accra, Addis Ababa, Ahmedabad, Algiers, Amman, Ankara, Antananarivo,
Ashgabat, Asmara, Astana, Athens, Baghdad, Baku, Bamako, Bandar Seri Begawan, Bangkok, Bangui,
Banjul, Beirut, Bengaluru, Berlin, Bishkek, Bloemfontein, Bogotá, Bern, Brasília, Bratislava,
Bucharest, Budapest, Buenos Aires, Cairo, Canberra, Cape Town, Caracas, Chennai, Coimbatore, Dakar,
Damascus, Dhaka, Dili, Djibouti city, Dodoma, Doha, Dublin, Dushanbe, Freetown, Gaborone, Ghaziabad,
Guwahati, Hanoi, Harare, Havana, Helsinki, Hobart, Hyderabad, Indore, Jaipur, Jakarta, Jerusalem,
Juba, Jurong East, Kabul, Kampala, Kanpur, Kathmandu, Kigali, Kinshasa, Kochi, Kolkata, Kuala Lumpur,
Kuwait City, Lisbon, Lilongwe, Lima, Lobamba, Lomé, London, Luanda, Lucknow, Lusaka, Malabo, Madrid,
Malé, Mexico City, Manama, Moscow, Manila, Maputo, Maseru, Mbabane, Mogadishu, Monrovia, Mumabi,
Muscat, Nagpur, Nairobi, New Delhi, Niamey, Nicosia, Noida, Nouakchott, N’Djamena, Oslo, Ottawa,
Ouagadougou, Panama City, Paris, Patna, Phnom Penh, Porto-Novo, Pretoria, Pune, Rabat, Reykjavík,
Riyadh, Rome, Sana’a, Santiago, Sri Jayawardenepura Kotte, Stockholm, Seoul, Singapore, Surat,
Suva, Taipei City, Tashkent, Tokyo, Tbilisi, Tehran, Thimphu, Tripoli, Tunis, Vientiane, Vilnius,
Visakhapatnam, Warsaw, Washington D.C., Wellington, Windhoek, Yaoundé, Yerevan, Naypyidaw
